Perimeter Overflow Grates

Parallel Grating

Daldorado’s SILENTFlow™ commercial pool grating system is the most superior evolution in parallel grating. All grating features the highest flow rate with an unprecedented 40% open area and whisper quiet noise reduction.

  • Our parallel grating conforms to both radius and straight configurations.
  • DPAS is available in standard 4", 10", 12”, 14” and 16” widths.
  • DPAR is available in standard 4", 10", 12". 14" and 16" widths.
  • Hand holds and curb angles available for true ledge support (radius or straight).

All corners are custom manufactured by Daldorado and strengthened for inside-outside corners per project design requirements. Fully warranted by Daldorado for manufacturers defects for 10-years.

Challenge-Free Installation
Daldorado’s SILENTFlow™ parallel grating has been engineered to make installation so easy you will want to install it on all your pools. Installed correctly by hand to Daldorado-Installation-Instructions it will minimize expansion issues.

Unprecedented Quality and Safety
Daldorado’s SILENTFlow™ parallel grating is manufactured using only the highest-grade materials Tested and Certified to NSF/ANSI/CAN 50 2020 with superior strength tested to ANSI/AS 3996 class A for covers and grates with loads exceeding 10kN (2,248lb), unparalleled safety tested to Section 3 of ANSI/APSP-16 for finger and limb entrapment and to AS 4586-2013 Classification C Wet-Barefoot inclining platform (ramp) test for slip resistance.

  • UV Exposure in accordance with ATSM G154 for UV resistance and 70% strength requirements of Section 3 of ANSI/APSP-16
  • Vertical load and deformation test of Section 3 of ANSI/APSP-16
  • Pull load requirements of Section 3 of ANSI/APSP-16

Features

Watch how well Daldorado SilentFlow Parallel Grating captures the water from the 250-gallon bucket drop, keeping the surrounding walkways free of water overflow.

Interactive CAD
Installation Demo

Radius Parallel Grate

Designer Specs

Install Instructions

4 Inch

4 Inch

Downloads

Viewers

10 Inch

10 Inch

Downloads

Viewers

12 Inch

12 Inch

Downloads

Viewers

14 Inch

14 Inch

Downloads

Viewers

16 Inch

16 Inch

Downloads

Viewers

Straight Parallel Grate

Designer Specs

Install Instructions

4 Inch

4 Inch

Downloads

Viewers

10 Inch

10 Inch

Downloads

Viewers

12 to 16 inch Parallel straight grating

12 Inch

12 Inch

Downloads

Viewers

12 to 16 inch Parallel straight grating

14 Inch

14 Inch

Downloads

Viewers

16 Inch

16 Inch

Downloads

Viewers

Custom

6 to 30 Inches

Downloads

Viewers



Aesthetics & Safety ~ All In One

Bare feet and wet swimming pool deck areas can be a dangerous combination, which means keeping your patrons and visitors safe is of the utmost importance. Through state-of-the-art engineering and rigorous testing, Daldorados grating features a powerful slip-resistant surface profile that is safety tested and certified to American Standards AS 4586-2013 Classification C Wet-Barefoot inclining platform (ramp) test for slip resistance factors in swimming pool surroundings, ramps and stairs leading to water, and communal shower and changing rooms.
